BUGATTI TYPE 35: CELEBRATING A CENTURY OF DESIGN, ENGINEERING AND RACING GENIUS

Without equal at its launch in 1924, the epoch-defining Bugatti Type 35 secured more than 2,500 race victories during its active time, and its beauty, technical ingenuity and driving brilliance remain just as appealing a century later.

To understand the Bugatti Type 35, one must first understand its creator, Ettore Arco Isidoro Bugatti. Without the one, there could have never been the other.

The Type 35 debuted with a 2.0-liter in-line eight-cylinder 24-valve engine that delivered 90 PS – class-leading performance for the day.

On its debut in 1924, the Bugatti Type 35 rewrote the rulebook to such an extent, introduced so many technical innovations and raised the art of motor racing to such new heights that it could only have come from a mind utterly unrestrained by the conventions and constraints of the time.

Ettore Bugatti possessed such a mind. Born into a family influenced by the arts, design and creativity for centuries, Bugatti’s interests were numerous and diverse, and his knowledge was extensive. Although he had many successful projects to his name before he created the Type 35, Bugatti was not a trained engineer.

It was instantly apparent upon its unveiling in 1924 that the Bugatti Type 35 had broken new ground.

Perhaps, in the case of the Type 35, the lack of formal training was an advantage, not an obstacle. If Bugatti had been tutored in traditional automotive engineering, he might not have pushed the boundaries quite so far with the Type 35. And he would certainly not have created the beautiful design attributes integral to each of the technical innovations found on the car. That the Bugatti Type 35 did break new ground to such startling and never-before-seen depths was instantly apparent to all observers in 1924.

Bugatti’s meticulous approach to development resulted in a car that set new standards for design, engineering, materials, handling, and performance.

“The Bugatti Type 35 was the world’s first purpose-designed and engineered race car. Unlike everything that had gone before, it was not a road car modified for racing, although it also served as a very fine road car. The meticulous approach Ettore Bugatti took to the overall concept, and to every minute detail, resulted in a car that set previously inconceivable standards for design, engineering, materials, handling and performance. The Bugatti Type 35 gave birth to the Grand Prix era and forced other motor manufacturers to completely rethink their approach.” – LUIGI GALLI – SPECIALIST FOR HERITAGE AND CERTIFICATION AT BUGATTI

Where other cars towered high above the ground, the Type 35’s bodywork sat low and sleek; where other cars sported wired wheels, the Type 35 rode on cast alloys – to reduce unsprung mass – with the brake drum mounted integrally in an equally revolutionary manner; and where other cars had their rear suspension exposed, on the Type 35, it was neatly encapsulated within the aluminium alloy panelled ellipsoid body. Although aerodynamics may have been a little understood science at the time, this pioneering approach further enhanced the low-drag nature of the bodywork.

Without equal at its launch in 1924, the Bugatti Type 35 secured more than 2,500 race victories during its lifetime.© BUGATTI TRUST

Underneath the body of the open-top two-seater, every detail was considered, nothing was left to chance, and almost everything represented a new and higher form of thinking.

The Type 35 debuted with a 2.0-litre in-line eight-cylinder, thin-wall 24-valve engine, which was subsequently enlarged to 2.3-litres and supercharged. The pioneering application of an aluminium crankshaft supported by two roller bearings and three ball bearings enabled the engine to rev up to 6,000 rpm and deliver 90 PS – class-leading performance for the day.

The Type 35 features an aluminum alloy-paneled ellipsoid body. This pioneering approach further enhanced the low-drag nature of the bodywork.© BUGATTI TRUST

Ettore Bugatti was acutely aware that superior performance was generated not solely by the addition of horsepower but also by the removal of weight. His dedication to ensuring every component was fabricated as light as possible, without compromising functionality or reliability, led to a vehicle weight of just 750 kg.

The Type 35 rode on cast alloys, to reduce unsprung mass, which incorporated an integral brake drum.© BUGATTI TRUST

The numerous measures Bugatti took to achieve his goal included the development of a new lightweight hollow front axle with sealed ends. The configuration of the rear axle was equally game-changing. Unlike conventional axles, it did not run ‘straight’ but dipped in the middle to fit around the chassis, rising at its ends to connect with the wheel hubs.

Ettore Bugatti and his son Jean in a Bugatti Type 35 at the Grand Prix de Lyon in 1924.© BUGATTI TRUST

Such innovations helped keep both the car’s height and weight low. Combined with the precision-engineered and calibrated steering system and a lightweight chassis incorporating the engine as a stressed load member, the Type 35 unlocked never-before-seen levels of agility, response and sheer driving pleasure.

Beautifully balanced cable-operated drum brakes and a petrol tank pressurized to optimize fuel flow were further elements engineered by Bugatti to enable drivers to exploit every ounce of the Type 35’s performance on road and track and show the chasing pack a clean pair of heels on more than 2,000 occasions and counting.

“At its launch in 1924, the Bugatti Type 35 served as a lodestone for the automotive industry, utterly transforming how vehicle design and engineering were perceived. A century later, its impact and allure have not diminished. The Type 35 is central to the marque’s DNA, along with the Bugatti Atlantic and the Bugatti Royale. Every automobile that Bugatti builds holds true to the design and engineering values of Ettore Bugatti so exquisitely expressed in the Type 35 one hundred years ago,” concludes Luigi Galli.

A century on from its unveiling, the impact and allure of the Type 35 have not diminished, and the model remains central to the marque’s DNA.

Every automobile that Bugatti builds today holds true to the design and engineering values that Ettore Bugatti so exquisitely expressed with the Type 35 a hundred years ago.
